品牌:YangXin
Table size:254*1270
Table tracvel:X(mm):800 Y(mm) 380,Z(mm) 370
Spindle Taper:R8/NT30
起订:1件
供应:100件
发货:15天内
立即购买
| Machine Model | Units | X6325A | |
| Demensions | mm | 254*1270 | |
| Inch | 10”*50” | ||
| Working table | X-axis | mm | 800 |
| Y-axis | mm | 380 | |
| Z-axis | mm | 370 | |
| ground way | Y-axis | Dovetail Guideway | |
| Z-axis | Dovetail Guideway | ||
| SPindle | Spindle Taper | R8/NT30 | |
| Spindle Travel | mm | 127 | |
| Spindle Speed | steps | 16 | |
| Spindle Feed | mm | 0.076/0.003" 0.038/0.0015" 0.203/0.008" | |
| Low Range | r/min | 66、110、175、270、550、930、1460、2270 | |
| High Range | r/min | 132、220、350、540、1100、1860、2920、4540 | |
| T-slot | Solt NumberX Width | mm | 3X16 |
| T-slot Pitsh | mm | 65 | |
| Voltage | V | 220/380/415 | |
| Motor | Frequency | HZ | 50/60 |
| Head Motor | HP | 3 | |
| Coolant Motor | HP | 1/8 | |
| MaxWorking Piece Weight | kg | 300 | |
| Saddle W*L | mm | 285*510 | |
| Ram Travel | mm | 370 | |
| Spindle Diameter | mm | 85.7 | |
| From spindle center to body | Min | mm | 230 |
| Max | mm | 600 | |
| From spindle nose to working table | Min | mm | 50 |
| Max | mm | 420 | |
| Machine Demension | mm | 1670*1680*2060 | |
| L*W*H | mm | ||
| Net Weight | KG | 1100 | |
