品牌:Yimu
Capacity:3500 - 5000 bottles/hour
Bottle diameter:Any size
Power supply:700W, 220V 60Hz, 1 phase
起订:1set
供应:10set
发货:30天内
Functions
l For automatic labeling on round bottles for the pharmaceuticals, daily chemicals, food & beverages industries.
l The labeler automatically detects the label size and the correct placement on the bottle, adjusting the labeling parameters accordingly. This feature is particularly useful for users with multiple products to label.
l It offers an optimal combination of speed, accuracy, stability, GMP standards, ease of use, and flexibility.
l Supported by a strong engineering team that provides customized solutions to meet the unique production needs of different customers.
l PLC combined with LCD touch screen controller.
l Precision stepper motor-driven labeling head.
l Labeling speed is automatically synchronized with conveyor speed to ensure quality labeling.
l Stainless steel frame construction and components are standard
Item | Parameter |
Label width(height) | 10-150mm |
Label length | 20-250mm |
Capacity | 3500 - 5000 bottles/hour |
Conveyor speed | 0-25m/min |
Bottle diameter | 30-100mm |
Labeling accuracy | ±1mm |
Power supply | 700W, 220V 60Hz, 1 phase |
Power supply | 220V 50Hz |
Machine size | L2050 * W920 * H1650 mm |
Reel Inner diameter | 75mm |
Reel outer diameter | Max 360mm |
Net weight | 250kg |
